| Manufacturer Part Number: | 78M6613-IMR/F/PP1 |
|---|---|
| Manufacturer: | Maxim Integrated |
| Product Category: | PMIC - Energy Metering |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | IC PWR MEASUREMENT AC 32SQFN |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | 78M6613-IMR/F/PP1 Datasheet |
| Internal Part Number | 898-78M6613-IMR/F/PP1 | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Mfg Application Notes | Using Current Transformers with the 78M661x 78M6613 Safety Precautions 78M6613 Printed Circuit Board Layout Guidelines 78M6613 Hardware Design Guidelines 78M661x Calibration Procedure 78M661x Sensor Selection Guide Achieving Significant Power from Renewables Adding Intelligence to LED Lighting Energy Measurement and Security for the Smart Grid - Too Long Overlooked Comparing OMU and HPL Solutions to the 78M6610+LMU | |
| PCN Part Status Change | Silergy Transfer 2/Mar/2016 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Energy Metering | |
| Manufacturer | Maxim Integrated | |
| Series | Teridian™ | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Discontinued | |
| Input Impedance | 40 kOhm ~ 90 kOhm | |
| Measurement Error | 0.5% | |
| Voltage - I/O High | 2V | |
| Voltage - I/O Low | 0.8V | |
| Current - Supply | 9.1mA | |
| Voltage - Supply | 3 V ~ 3.6 V | |
| Meter Type | Single Phase | |
| Operating Temperature | -40°C ~ 85°C | |
| Mounting Type | Surface Mount | |
| Package / Case | 32-VFQFN Exposed Pad | |
| Supplier Device Package | 32-SQFN (5x5) | |
| Standard Package | 2,500 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | 78M6613-IMR/F/PP1 | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
78M6613-IMR/F/PP1 is in stock for immediate shipping now. We are the distributor of Maxim Integrated all series components. The condition of 78M6613-IMR/F/PP1 is new and unused, you can buy 78M6613-IMR/F/PP1 Maxim Integrated with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for 78M6613-IMR/F/PP1.
