| Manufacturer Part Number: | DAC811AH |
|---|---|
| Manufacturer: | T-I |
| Product Category: | Data Acquisition - Digital to Analog Converters (DAC) |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | 12 Bit Digital to Analog Converter 1 28-CDIP SB |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | DAC811AH Datasheet |
| Internal Part Number | 898-DAC811AH | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Product Training Modules | Data Converter Basics | |
| Manufacturer Product Page | DAC811AH Specifications | |
| EDA / CAD Models | Download from Accelerated Designs | |
| Category | Integrated Circuits (ICs) | |
| Family | Data Acquisition - Digital to Analog Converters (DAC) | |
| Manufacturer | T I | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Active | |
| Number of Bits | 12 | |
| Number of D/A Converters | 1 | |
| Settling Time | 4µs | |
| Output Type | Voltage - Buffered | |
| Differential Output | No | |
| Data Interface | Parallel | |
| Reference Type | Internal | |
| Voltage - Supply, Analog | ±11.4 V ~ 16.5 V | |
| Voltage - Supply, Digital | 5V | |
| INL/DNL (LSB) | ±0.25, ±0.5 | |
| Architecture | R-2R | |
| Operating Temperature | -25°C ~ 85°C | |
| Package / Case | 28-CDIP (0.600", 15.24mm) | |
| Supplier Device Package | 28-CDIP SB | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | DAC811AH | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
DAC811AH is in stock for immediate shipping now. We are the distributor of T-I all series components. The condition of DAC811AH is new and unused, you can buy DAC811AH T-I with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for DAC811AH.
