| Manufacturer Part Number: | FGA60N65SMD |
|---|---|
| Manufacturer: | Fairchild Semiconductor |
| Product Category: | Transistors - IGBTs - Single |
| Available Quantity: | 9627 Pieces |
| Unit Price: | Quote by Email |
| Description: | IGBT Field Stop 650V 120A 600W Through Hole TO-3P |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | FGA60N65SMD Datasheet |
| Internal Part Number | 898-FGA60N65SMD | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Heat Sink Drawing Update 11/Feb/2014 | |
| PCN Assembly/Origin | Assembly Site Transfer 06/Apr/2015 | |
| PCN Packaging | Tape and Box/Reel Barcode Update 07/Aug/2014 | |
| Online Catalog | Standard IGBTs | |
| Category | Discrete Semiconductor Products | |
| Family | Transistors - IGBTs - Single | |
| Manufacturer | Fairchild Semiconductor | |
| Series | - | |
| Packaging | Tube | |
| Part Status | Active | |
| IGBT Type | Field Stop | |
| Voltage - Collector Emitter Breakdown (Max) | 650V | |
| Current - Collector (Ic) (Max) | 120A | |
| Current - Collector Pulsed (Icm) | 180A | |
| Vce(on) (Max) @ Vge, Ic | 2.5V @ 15V, 60A | |
| Power - Max | 600W | |
| Switching Energy | 1.54mJ (on), 450µJ (off) | |
| Input Type | Standard | |
| Gate Charge | 189nC | |
| Td (on/off) @ 25°C | 18ns/104ns | |
| Test Condition | 400V, 60A, 3 Ohm, 15V | |
| Reverse Recovery Time (trr) | 47ns | |
| Package / Case | TO-3P-3, SC-65-3 | |
| Mounting Type | Through Hole | |
| Supplier Device Package | TO-3P | |
| Standard Package | 30 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | FGA60N65SMD | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
FGA60N65SMD is in stock for immediate shipping now. We are the distributor of Fairchild Semiconductor all series components. The condition of FGA60N65SMD is new and unused, you can buy FGA60N65SMD Fairchild Semiconductor with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for FGA60N65SMD.
