| Manufacturer Part Number: | LC05111C02MTTTG |
|---|---|
| Manufacturer: | ON Semiconductor |
| Product Category: | PMIC - Battery Management |
| Available Quantity: | 14824 Pieces |
| Unit Price: | Quote by Email |
| Description: | Battery Battery Protection IC Lithium-Ion 6-WDFN (4x2.6), Dual Flag |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 3 (168 Hours) |
| Production Status (Lifecycle): | In Production |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | LC05111C02MTTTG Datasheet |
| Internal Part Number | 898-LC05111C02MTTTG | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| PCN Design/Specification | Datasheet Update 09/Apr/2015 | |
| Online Catalog | Over/Under Voltage Protection | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - Battery Management | |
| Manufacturer | ON Semiconductor | |
| Series | - | |
| Packaging | Digi-Reel® | |
| Part Status | Active | |
| Function | Battery Protection | |
| Battery Chemistry | Lithium-Ion | |
| Number of Cells | 1 | |
| Fault Protection | Over Current | |
| Interface | - | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Package / Case | 6-PowerWDFN | |
| Supplier Device Package | 6-WDFN (4x2.6), Dual Flag | |
| Drawing Number | 488; 511BZ; ; 6 | |
| Standard Package | 1 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | LC05111C02MTTTG | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
LC05111C02MTTTG is in stock for immediate shipping now. We are the distributor of ON Semiconductor all series components. The condition of LC05111C02MTTTG is new and unused, you can buy LC05111C02MTTTG ON Semiconductor with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for LC05111C02MTTTG.
