| Manufacturer Part Number: | NCP5680MUTXG |
|---|---|
| Manufacturer: | ON Semiconductor |
| Product Category: | PMIC - LED Drivers |
| Available Quantity: | 9010 Pieces |
| Unit Price: | Quote by Email |
| Description: | LED Driver IC 2 Output DC DC Controller Switched Capacitor (Charge Pump) 24-UQFN (3.5x3.5) |
| Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
| Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
| Production Status (Lifecycle): | Obsolete / Discontinued |
| Delivery Time: | 1-2 Days |
| Date Code (D/C): | New |
| Datasheet Download: | NCP5680MUTXG Datasheet |
| Internal Part Number | 898-NCP5680MUTXG | |
| Manufacturer Lead time | 6-8 weeks | |
| Condition | New & Unused, Original Sealed | |
| Design Resources | Lighting Product Selector | |
| PCN Obsolescence/ EOL | Multiple Devices 30/Jun/2011 | |
| Category | Integrated Circuits (ICs) | |
| Family | PMIC - LED Drivers | |
| Manufacturer | ON Semiconductor | |
| Series | - | |
| Packaging | Tape & Reel (TR) | |
| Part Status | Obsolete | |
| Type | DC DC Controller | |
| Topology | Switched Capacitor (Charge Pump) | |
| Internal Switch(s) | No | |
| Number of Outputs | 2 | |
| Voltage - Supply (Min) | 2.7V | |
| Voltage - Supply (Max) | 5.5V | |
| Voltage - Output | 4.5 V ~ 5.3 V | |
| Current - Output / Channel | - | |
| Frequency | 1MHz | |
| Dimming | - | |
| Applications | Camera Flash | |
| Operating Temperature | -40°C ~ 85°C (TA) | |
| Mounting Type | Surface Mount | |
| Package / Case | 24-UFQFN Exposed Pad | |
| Supplier Device Package | 24-UQFN (3.5x3.5) | |
| Standard Package | 3,000 | |
| Weight | 0.001 KG | |
| Application | Email for details | |
| Replacement Part | NCP5680MUTXG | |
| Country of Origin | USA / JAPAN / Philippines / Malaysia | |
| MOQ | 1 Piece | |
| Picture / Image / Photo | Send via email | |
NCP5680MUTXG is in stock for immediate shipping now. We are the distributor of ON Semiconductor all series components. The condition of NCP5680MUTXG is new and unused, you can buy NCP5680MUTXG ON Semiconductor with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for NCP5680MUTXG.
