Manufacturer Part Number: | ADG201HSJPZ |
---|---|
Manufacturer: | Analog Devices Inc. |
Product Category: | Interface - Analog Switches, Multiplexers, Demultiplexers |
Available Quantity: | 9010 Pieces |
Unit Price: | Quote by Email |
Description: | 4 Circuit IC Switch 1:1 50 Ohm 20-PLCC (9x9) |
Lead Free Status / RoHS Status: | Lead free / RoHS Compliant |
Moisture Sensitivity Level (MSL): | 1 (Unlimited) |
Production Status (Lifecycle): | In Production |
Delivery Time: | 1-2 Days |
Date Code (D/C): | New |
Datasheet Download: | ADG201HSJPZ Datasheet |
Internal Part Number | 898-ADG201HSJPZ | |
Manufacturer Lead time | 6-8 weeks | |
Condition | New & Unused, Original Sealed | |
Product Training Modules | Switch Fundamentals | |
EDA / CAD Models | Download from Accelerated Designs | |
Online Catalog | Switch | |
Category | Integrated Circuits (ICs) | |
Family | Interface - Analog Switches, Multiplexers, Demultiplexers | |
Manufacturer | Analog Devices Inc. | |
Series | - | |
Packaging | Tube | |
Part Status | Active | |
Switch Circuit | SPST - NC | |
Multiplexer/Demultiplexer Circuit | 1:1 | |
Number of Circuits | 4 | |
On-State Resistance (Max) | 50 Ohm | |
Channel-to-Channel Matching (ΔRon) | 1.5 Ohm | |
Voltage - Supply, Single (V+) | 10.8 V ~ 16.5 V | |
Voltage - Supply, Dual (V±) | ±13.5 V ~ 16.5 V | |
Switch Time (Ton, Toff) (Max) | 75ns, 75ns | |
-3db Bandwidth | - | |
Charge Injection | 10pC | |
Channel Capacitance (CS(off), CD(off)) | 10pF, 10pF | |
Current - Leakage (IS(off)) (Max) | 1nA | |
Crosstalk | -86dB @ 100kHz | |
Operating Temperature | -40°C ~ 85°C (TA) | |
Package / Case | 20-LCC (J-Lead) | |
Supplier Device Package | 20-PLCC (9x9) | |
Standard Package | 49 | |
Weight | 0.001 KG | |
Application | Email for details | |
Replacement Part | ADG201HSJPZ | |
Country of Origin | USA / JAPAN / Philippines / Malaysia | |
MOQ | 1 Piece | |
Picture / Image / Photo | Send via email |
ADG201HSJPZ is in stock for immediate shipping now. We are the distributor of Analog Devices Inc. all series components. The condition of ADG201HSJPZ is new and unused, you can buy ADG201HSJPZ Analog Devices Inc. with us at a very low price and quick delivery.
Please kindly send us an email if you have any demands for ADG201HSJPZ.
